12V 25Ah LiFePO4 Deep Cycle Battery


Lithium Master

ALF-012025A + CRF-1205P

Out of stock

Regular price $229.99
The Lithium Master 12V 25Ah LiFePO4 Battery is a state-of-the-art rechargeable battery pack made with Lithium Iron Phosphate (LFP) cells designed for 12V devices. It is perfect for e-scooters, e-bikes, solar applications, robots, and other applications that require a higher energy density battery. This 12V battery comes with integrated Anderson Power...

The Lithium Master 12V 25Ah LiFePO4 Battery is a state-of-the-art rechargeable battery pack made with Lithium Iron Phosphate (LFP) cells designed for 12V devices. It is perfect for e-scooters, e-bikes, solar applications, robots, and other applications that require a higher energy density battery. This 12V battery comes with integrated Anderson Power Pole connectors making it a perfect drop-in solution for your applications. Lithium Master batteries have a built-in battery management system (BMS) that keeps the battery running at peak performance and protects the cells for thousands of cycles, including over-charge, over-discharge, over-current, and short-circuit protection.

    View Manual

    Specifications

    Battery Type ABS Case
    Battery Chemistry Lithium Iron Phosphate
    Cell Type/Assembly Method Cylindrical cells/welded
    Voltage (V) 12V
    Capacity (Ah) 25Ah
    Energy Stored (Wh) 300 Watt-Hours
    Weight 5.8 lbs. (0.95 kg)
    Dimension Metric (L x W x H) 182 mm x 77 mm x 171 mm
    Dimension Imperial (L x W x H) 7.2 in. x 3.2 in. x 6.7 in.
    Discharge Connector M8 Screw Terminal
    Charge Connector  M8 Screw Terminal
    Cycle Life 3000+ cycles
    Normal Charge Current 4.0 Amps
    Maximum Continuous Charge Current 6.0 Amps
    Nominal Continuous Discharge Current 15.0 Amps
    Maximum Continuous Discharge Current 30.0 Amps
    Maximum Pulse (Peak) Discharge Current (2 sec.) 40.0 Amps
    Charge Temperature 0°C to 45°C
    Discharge Temperature -20°C to 60°C
    Operating Humidity 60±25%R.H
    Storage Humidity 60±25%R.H
    Automatic Battery Protection Module/System Low Voltage Disconnect,
    Over Voltage Disconnect,
    Short Circuit Protection,
    Reverse Polarity Protection,
    Cell Balancing,



    12V 5A LiFePO4 Battery Charger Specs

    LFP Advantage

    • Advanced LFP (Lithium Iron Phosphate) Li-ion Chemistry superior to traditional Li-ion Batteries
    • All-Aspect Solution with best overall balance of features
    • High Specific Energy (90-120Wh/kg)
    • Designed Specifically for Marine, RV and Deep Discharge Electronics
    • Excellent Lifespan (3000+ Cycles Average)

    lfp lifepo4 lithium battery by lithium master


    Intelligent Technology

    • Battery Management System (BMS) Board as Standard
    • Every Battery has bespoke board matching its performance parameters
    • Comprehensively balances charging and discharging
    • Internal balancing circuitry and charger circuitry inside BMS
    • Comprehensive protections against over-charge, over-discharge, over-voltage, over-current, short circuits, reverse polarity, thermal protection
    • Dramatically extends service life

    Improvements

    • Achieve full depth discharge of 100% Label Capacity
    • “True Lithium Capacity” guarantees capacity of purchase is capacity delivered
    • Reliable, repeatable full depth cycling without system life cycle degradation
    • LFP Systems can be fully discharged safely without impact on system performance
    • Multiple times usable capacity of Lead Acid



    Policy
    Warranty: 10 years LFP Battery Warranty
    30 Day Money Back Return | 5 Year Repair/Replace | 6 -10 Year Pro Rated Based on Remaining Capacity
    Cancellation: Within 24 Hours ⟶ No charge
    Shipping: Standard within 2 business days
